.696 - .760 Diameter

(Patent # 5,259,707)

L

D.O.C.

130° Range S

Drill Sergeants
Size

Standard Inserts

Size Range
Tool #
S
L
Helical Flute Tool Info. 5.000 D.O.C. Coolant Plug .750
NPT 1/8

.696 - .760
1.500
DS-69-76S
DI-718 / DI-750
DS-69-76L

DI-718 / DI-750
3.000
.696 - .760
N/A
6.500
N/A
4.500
8.000
DS-69-76XL
DI-718 / DI-750

.696 - .760
Straight Flute Tool Info.
Tool # Size Range Standard Inserts L D.O.C. Coolant Plug S
DSL-69-76L .696 - .760 DI-718 / DI-750 6.500 3.000
NPT 1/8 .750
DSL-69-76XL .696 - .760 DI-718 / DI-750 8.000 4.500
Use Straight Flute For Lathe and High Pressure Coolant Applications over 500 P.S.I.
Speed and Feed Info.

Diameter Tolerance
D Material S.F.M. I.P.R.
+/-.002 Mild & Low Carbon Steel 700 - 900 .004 - .006
Ex. 1018, 1020, 1117, 1141, 12L14
High Carbon & Alloy Steel 500 - 600 .004 - .006
Insert Info Ex. 1045, 4140, 4340, 52100, 8620
Insert # D Screw Wrench Grade Lower Carbon Tool Steel 400 - 500 .004 - .006
Ex. P-20, H-13, S-7
DI-718 .7188 Tool Steel
314T T-8 X33 350 - 450 .004 - .006
DI-750 .7500 Ex. A-2, A-6, D-2, M-2
Stainless Steel 350 - 550 .004 - .006
Ex. 304, 316, 420, 15-5PH, 17-4PH
Iron 600 - 800 .005 - .008
Ex. Cast, Ductile, Nodular
Nickel & Titanium Alloy 100 - 200 .001 - .003
Ex. Inconel, Hastelloy, TI-6AL-4V
Non-Ferrous Metal 1000 - 2000 .005 - .008
Ex. Aluminum, Bronze, Brass
